Product Description
Easy calibration. The metering precision can be adjusted to the viscosity using the calibration scale. Easy-to-read 5-digit display. Resettable display. Impact-resistant electronics. Standby mode after 10 minutes without using the system.
- Grease meter with batteries, spout, and retention adapters
- Battery LR1 Lady Duracell-MN9100
- Spout, 80 mm , 25°, R 1/8" male, R 1/8" male
- Retention adapter, steel, galvanized, G 1/8'' female, M 10 x 1 male
- Retention adapter, steel, galvanized, R 1/8'' female, M 10 x 1 male
TECHNICAL SPECIFICATIONS
- Connection 1 G 1/8 " female
- Connection 2 G 1/8 " female
- Designed for use with greases NLGI 1-2
- Units Calibratable in liters or cm³
- Performance 0-1000 cm³/min
- Max. operating pressure (bar) 700
- Burst pressure (bar) 1000
- Temperature range (°C) -20/+60
- Material of housing Aluminum
- Repeat accuracy 0-300 bar ±1%
- Display partial volumes and totalizator
- Lifetime of battery approx. 2 years
- 5-digits display, partial volume and totalizator, resettable
